Tree Removal

Built for demanding land-clearing applications, tree removal attachments provide the power and versatility needed to cut, remove, and manage trees and brush while maximizing productivity and jobsite efficiency.

FIND A DEALER

Available Models

Find the right attachment to meet the needs of your operation.

Stump Grinder | SE32

SE32 SSL STMPGRND 32
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
FLOW: 20–45 gpm
MAX psi: 4,250 psi
WEIGHT: 1,475 lb

Stump Grinder | SG12L

SG12L SAL STMPGRND 18
EQUIPMENT: SMALL ARTICULATED LOADER
WEIGHT: 475 lb
FLOW: 7–17 gpm
MAX CUTTING DIAMETER: 36"
MAX CUTTING DEPTH: 6"
ARC: 66°
CUTTING WHEEL DIAMETER: 18"
CUTTING WHEEL SPEED: 500–1,000 RPM
NUMBER OF TEETH: 24

Stump Grinder | SG12M

SG12M CII STMPGRND 18
EQUIPMENT: MINI TRACK LOADER
WEIGHT: 415 lb
FLOW: 7–17 gpm
MAX CUTTING DIAMETER: 36"
MAX DEPTH: 6"
CUTTING ARC: 66°
CUTTING WHEEL DIAMETER: 18"
CUTTING WHEEL SPEED: 500–1,000 RPM
NUMBER OF TEETH: 24

Stump Grinder | SG16H

SG16H SSL STMPGRND 24HF
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
GRINDS STUMPS: UP TO 12" BELOW GROUND LEVEL
60° RANGE OF MOTION: COVERS 45" IN A SINGLE SWEEP
HIGH FLOW: 25–42 gpm
WEIGHT: 860 lb
MAX PRESSURE: 3,000 psi

Stump Grinder | SG16S

SG16S SSL STMPGRND 24S
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
GRINDS STUMPS: UP TO 12" BELOW GROUND LEVEL
60° RANGE OF MOTION: COVERS 45" IN A SINGLE SWEEP
STANDARD FLOW: 15–22 gpm
WEIGHT: 790 lb
MAX PRESSURE: 3,000 psi

Stump Lifter | STU10

STU10 SSL STMPROOT 36
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
STEEL CONSTRUCTION: 5/16"
STEEL TIP: 3/8" AR400
MAX HORSEPOWER: 45
WEIGHT: 164 lb
LENGTH: 37"

Stump Planer | AD12SP

AD12SP SSL STMPGRND 12
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
BIT STYLE: PLANER
CUT: 12"
PILOT CONE: INCLUDED

Stump Planer | AD16SP

AD16SP SSL STMPGRND 16
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
BIT STYLE: PLANER
CUT: 16"
PILOT CONE: INCLUDED

Tree Puller | TP10H

TP10H SSL TREEPULL HD
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
MAX TREE DIAMETER: 12"
MAX JAW OPENING: 43"
HEIGHT: 19"
WIDTH: 51"
LENGTH: 53"
WEIGHT: 1,250 lb

Tree Puller | TP10S

TP10S SSL TREEPULL
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
MAX TREE DIAMETER: 8"
MAX JAW OPENING: 12"
HEIGHT: 31"
WIDTH: 48"
LENGTH: 40"
WEIGHT: 336 lb

Tree Spade | SPD24

SPD24 CII TREESPD_24
EQUIPMENT: MINI TRACK LOADER
WEIGHT: 110 lb
BLADE ANGLE: 75°
BLADE THICKNESS: 0.25"
MAX EVERGREEN TREE DIAMETER: 1.5"
MAX HARDWOOD TREE DIAMETER: 1"
ROOT BALL DIAMETER: 22"

Tree Spade | TRSP2625

TRSP2625 SSL TREESPD_26
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER
OVERALL HEIGHT (BLADES UP, OPEN): 51"
OVERALL HEIGHT (BLADES DOWN, CLOSED): 53.5"
SHIPPING HEIGHT - (BLADES REMOVED): 32"
FRAME HEIGHT: 22.5"
DIGGING DEPTH: 22"
CUTTING ANGLE: 25°
OVERALL TRANSPORT WIDTH (GATE CLOSED): 51"
OVERALL WIDTH (GATE OPEN, BLADES UP): 66.5"
MAXIMUM GATE OPENING: 29"
OVERALL LENGTH (GATE OPEN: 64"
OVERALL TRANSPORT LENGTH (GATE CLOSED): 63"
MAXIMUM LEG ADJUSTMENT: 10.5"
NUMBER OF BLADES: 3
TREE BALL DIAMETER: 18"–26"
TREE DIAMETER: 1.5"–2.5"
BALL WEIGHT: 1,200–1,400 lb
FLOW REQUIREMENTS: 10 gpm
RECOMMENDED OPERATING PRESSURE: 2,250 psi
WEIGHT: 1,100 lb

Tree Spade | TRSP3625

TRSP3625 SSL TREESPD_36
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER, COMPACT WHEEL LOADER
OVERALL HEIGHT (BLADES UP, OPEN): 64.5"
OVERALL HEIGHT (BLADES DOWN, CLOSED): 69"
SHIPPING HEIGHT (BLADES REMOVED): 38"
FRAME HEIGHT: 22.50"
DIGGING DEPTH: 31"
CUTTING ANGLE: 25°
OVERALL TRANSPORT WIDTH (GATE CLOSED): 66"
OVERALL WIDTH (GATE OPEN, BLADES UP): 88.5"
MAXIMUM GATE OPENING: 40"
OVERALL LENGTH (GATE OPEN): 75"
OVERALL TRANSPORT LENGTH (GATE CLOSED): 68"
MAXIMUM LEG ADJUSTMENT: 10.5"
NUMBER OF BLADES: 3
TREE BALL DIAMETER: 24" – 36"
TREE DIAMETER: 2"–3.5"
BALL WEIGHT: 250–1,000 lb
FLOW REQUIREMENTS: 10 gpm
RECOMMENDED OPERATING PRESSURE: 2,250 psi
WEIGHT: 1,500 lb

Tree Spade | TRSP4425

TRSP4425 SSL TREESPD_44
EQUIPMENT: SKID STEER LOADER, COMPACT TRACK LOADER, COMPACT WHEEL LOADER
OVERALL HEIGHT (BLADES UP, OPEN): 64.5"
OVERALL HEIGHT (BLADES DOWN, CLOSED): 69"
SHIPPING HEIGHT (BLADES REMOVED): 38"
FRAME HEIGHT: 22.5"
DIGGING DEPTH: 31"
CUTTING ANGLE: 25°
OVERALL TRANSPORT WIDTH (GATE CLOSED): 63"
OVERALL WIDTH (GATE OPEN, BLADES UP): 107"
MAXIMUM GATE OPENING: 33"
OVERALL LENGTH (GATE OPEN): 68"
OVERALL TRANSPORT LENGTH (GATE CLOSED): 69.5"
MAXIMUM LEG ADJUSTMENT: 10.5"
NUMBER OF BLADES: 4
TREE BALL DIAMETER: 30" – 44"
TREE DIAMETER: 3"–4.5"
BALL WEIGHT: 1,200–1,400 lb
FLOW REQUIREMENTS: 10 gpm
RECOMMENDED OPERATING PRESSURE: 2,250 psi
WEIGHT: 1,825 lb
